PROLIGHTS - EclFresnel TW / PTW 23
BARN DOOR (CODE ECLFRSBD - OPTIONAL)
DETAIL-2
3
2
DETAIL-1
1
Press the pin (1) and the snap will automatically open upwards (2). Insert the barn door (3) into the gel frame
lock (DETAIL-1) throught the holder assembly of the barn door (DETAIL-2). Then close down the snap.
NOTE: To remove the accessory, reverse the procedure.
Fig.10
