PROLIGHTS - EclFresnel TW / PTW22
12 - ACCESSORIES INSTALLATION
FILTER FRAME (CODE ECLFRSTPG - OPTIONAL)
2
3
DETAIL
1
Press the pin (1) and the snap will automatically open upwards (2). Insert the gel lter frame (3) into
the gel frame lock (DETAIL) and close down the snap.
NOTE: To remove the accessory, reverse the procedure.
Fig. 09
