PROLIGHTS - EclFresnel TW / PTW24
NARROW ANGLE LENS (CODE ECLFRSNL - OPTIONAL)
2
3
DETAIL
1
Press the pin (1) and the snap will automatically open upwards (2). Insert the narrow angle lens (3) into
the gel frame lock (DETAIL) and close down the snap.
NOTE: To remove the accessory, reverse the procedure.
Fig. 11
