EVO64CYC
14
Ch Function in TOUR mode Value
10
AUTO SPEED
Since the walking speed (slow to fast) 000 - 255
11
DIMMER SPEED
Return settings
Normal
DIM1
DIM2
DIM3
DIM4
000 - 009
010 - 029
030 - 069
070 - 129
130 - 189
190 - 255
Ch Function in TR16 mode Value
1 MASTER DIMMER 000 - 255
2
MASTER DIMMER FINE
(CH15 select CUSTOM 01-10, CH2 CONTROL TIME)
000 - 255
3
RED
(CH15 select CUSTOM 01-10, CH3 CONTROL FADE) 000 - 255
4 RED FINE 000 - 255
5 GREEN 000 - 255
6 GREEN FINE 000 - 255
7 BLUE 000 - 255
8 BLUE FINE 000 - 255
9 WHITE 000 - 255
10 WHITE FINE 000 - 255
11 AMBER 000 - 255
12 AMBER FINE 000 - 255
13
COLOR MACRO+WHITE BALANCE
No function
Red 100%/Green Up/Blue 0%
Red Down/Green 100%/Blue 0%
Red 0%/Green 100%/Blue Up
Red 0%/Green Down/Blue 100%
Red Up/Green 0%/Blue100%
Red 100%/Green 0%/Blue Down
Red 100%/Green Up/Blue Up
Red Down/Green Down/Blue 100%
All LEDs 100%
White 1: 3200K
White 2: 3400K
White 3: 4200K
White 4: 4900K
White 5: 5600K
White 6: 5900K
White 7: 6500K
000 - 010
011 - 030
031 - 050
051 - 070
071 - 090
091 - 110
111 - 130
131 - 150
151 - 170
171 - 200
201 - 205
206 - 210
211 - 215
216 - 220
221 - 225
226 - 230
231 - 235
TR16
CH Function in PIX1 Value
1 P1 RED 0 - 100% 000 - 255
2 P1 GREEN 0 - 100% 000 - 255
3 P1 BLUE 0 - 100% 000 - 255
4 P2 RED 0 - 100% 000 - 255
5 P2 GREEN 0 - 100% 000 - 255
6 P2 BLUE 0 - 100% 000 - 255
PIX1
