The machine is equipped with the following protective
devices:
● complete panelling protection of all the parts
subject to heat and of the steam and hot water
supplier;
● cup-warmer plate supplied with a tray to collect
spilt liquids;
● work surface provided with grill and tray to collect
spilt liquids;
● buttons in a safe place above the dispensing
area;
● expansion valve in the hydraulic system and valve
on the boiler to avoid overpressure;
● nonreturn valve on the hydraulic system to avoid
owing back to the main supply.
The safety devices provided are:
● thermal protection on the pump motor;
● gas failure thermocouple and thermocouple control
thermostat automatically closing gas tap;
● resistance protection thermal relai.
Noise level in the work place does not usually exceed
70dB(A).
The machine is supplied with rubber vibration dam-
ping feet. In normal working conditions, the machine
does not produce vibrations harmful to the operator
and the environment.
Models equipped with gas connections (when applied).
(Fig.4)
COMPACT
2 Groups
3 Groups
1 dose lter holder 1 1 1
2 dose lter holder 1 2 3
Filters 2 3 4
Blind lter 1 1 1
0,8 mt. supply pipe 1 2 2
1,8 mt. supply pipe 1 1 1
2 mt. drainage pipe 1 1 1
Pipe connections 1 1 1
Instruction manual 1 1 1
Brush 1 1 1
Wiring diagram 1 1 1
COMPACT
2 Goups 2 Groups
TALL
3 Groups 3 Groups
TALL
A mm 385 580 765 1005
B mm 234 436 621 861
C mm 370 310 310 310
D mm 530 530 530 530
H mm 560 560 560 560
Boiler capacity in litr.
4 5 11 16
Machine weight kg
30 52 68 88
Water inlet
3/8 3/8 3/8 3/8
Ømm drainage
14 14 14 14
Packaging
Package nr.
1 1 1 1
Volume m
3
0,21 0,27 0,44 0,55
Dimensions mm
L
P
H
500
690
600
660
670
600
910
670
720
1150
670
720
Gross weight kg 34 71 73 93
75
