ProMinent CONCEPT PLUS Series User Manual

18
ProMinent
®
CNPA
Identcode
Please enter the Identcode listed on the rating plate under “Type” into the space below.
CNPA series CONCEPT
PLUS
, Version a
CNPA with 180 strokes/min CNPA with 240 strokes/min
Type Power
CNPA bar I/h CNPA bar I/h
1000 10 0.74 1001 10 1.0
1601 16 1.1 1602 16 1.5
1002 10 2.1 1003 10 2.7
0704 7 3.9 0705 7 5.2
0308 3 8.5 0311 3 11.4
0215 1.5 14.9 0220 1.5 19.9
Material
PP Polypropylene
NP Acrylglass/PVC
PV PVDF
Diaphragm and gaskets
E Standard with EPDM gaskets
B Standard with FDM gasket
T Standard with PTFE flat gasket
Liquid end type
0 without vent, without valve spring
1 without vent, with valve spring
2 with vent, without valve spring
3 with vent, with valve spring
Hydraulic connection
0 Standard connection
Type
0 with ProMinent logo
Electrical connection
A 230 V, European connector
B 230 V, Swiss connector
C 230 V, Australian connector
D 115 V, USA connector
Control type
0 Standard
A with external and level input refitting kit
B with external and level input refitting kit, assembled
Accessories
0 without accessories
1 with accessories
Identcode
BA_CO_016_06_07_4spr.p65 21.06.2007, 12:48 Uhr18
