25
ProMinent
®
Decommissioning and disposal / Technical data
9 Decommissioning and disposal
IMPORTANT
• When decommissioning a pump, clean all traces of chemicals
and dirt from the housing and particularly the liquid end.
• Observe all relevant disposal directives for your area
(particularly with regard to electronic waste)
10 Technical data
Output diagram at 180 strokes/min
* Suction lift with filled suction line and liquid end
** Suction heights with clean as well as moistened valves, with
metering medium water (20 °C), 100% stroke length, max. stroke
frequency, free outlet or opened vent valve and properly installed
piping system.
Leistungstabelle bei 240 Hüben/min
Pump min. output at min. output at mean max. no. Conn. size Suction Suction Permissible
type maximum backpressure of strokes outer Ø • height* height** pre-pressure
backpressure inner Ø suction side
Strokes/
bar l/h ml/stroke bar l/h ml/stroke min mm m WC m WC bar
1001 10 1.0 0.069 5 1.3 0.09 240 6x4 6 1.8 8
1602 16 1.5 0.10 8 1.9 0.13 240 6x4 6 2.0 8
1003 10 2.7 0.19 5 3.5 0.24 240 6x4 5 2.5 5
0705 7 5.2 0.36 3.5 5.9 0.41 240 6x4 4 3.0 4
0311 3 11.4 0.79 1.5 14.4 1.0 240 8x5 2 2.0 1
0220 1.5 19.9 1.38 1.0 23.4 1.63 240 8x5 1.5 1.5 0.5
Pump min. output at min. output at mean max. no. Conn. size Suction Suction Permissible
type maximum backpressure of strokes outer Ø • height* height** pre-pressure
backpressure inner Ø suction side
Strokes/
bar l/h ml/stroke bar l/h ml/stroke min. mm m WC m WC bar
1000 10 0.74 0.07 5 0.8 0.08 180 6x4 6 1.8 8
1601 16 1.1 0.1 8 1.4 0.13 180 6x4 6 2.0 8
1002 10 2.1 0.19 5 2.6 0.24 180 6x4 5 2.5 5
0704 7 3.9 0.36 3.5 4.5 0.42 180 6x4 4 3.0 3
0308 3 8.5 0.79 1.5 10.8 1.00 180 8x5 2 2.0 1
0215 1.5 14.9 1.38 1.0 15.5 1.4 180 8x5 1.5 1.5 0.5
BA_CO_016_06_07_4spr.p65 21.06.2007, 12:48 Uhr25
