CNPb performance table for 240 strokes/min
Type Minimum pump
capacity
at maximum back
pressure
Minimum pump
capacity
at medium back pres‐
sure
Con‐
nector
size
outside Æ
x inside Æ
Suc‐
tion
lift*
Pri‐
ming
lift**
Max.
priming
pres‐
sure
on the
suction
side
bar l/h ml/
strok
e
bar l/h ml/
stroke
mm m WS m WS bar
concept
plus
1001 10 1.0 0.07 5.0 1.3 0.09 6x4 6.0 1.8 8
1602 16 1.5 0.10 8.0 1.9 0.13 6x4 6.0 2.0 8
1003 10 3.0 0.21 5.0 4.3 0.30 6x4 5.0 2.5 5
0705 7 5.2 0.36 3.5 5.9 0.41 6x4 4.0 3.0 3
0312 3 12.0 0.83 1.5 17.3 1.20 8x5 2.0 2.0 1
0223 1.5 21.9 1.52 1.0 25.2 1.75 8x5 1.5 1.5 0.5
concept
plus
metering pumps with self-bleeding dosing head SER***
1003 10 2.4 0.17 5.0 3.06 0.25 6x4 1.8 1.8 5
0705 7 4.2 0.29 3.5 5.2 0.36 6x4 1.8 1.8 3
0312 3 12.9 0.83 1.5 17.6 1.22 8x5 1.8 1.8 1
0223 1.5 18.6 1.29 - - - 8x5 1.8 1.8 0.5
* Suction lifts with a filled suction line and filled liquid end
** Priming lifts with clean and moist valves, feed chemical water (20 °C), at 100% stroke length,
max. stroke rate, free outlet or opened bleed valve and correctly installed piping.
**The given performance data constitutes guaranteed minimum values, calculated using medium
water at room temperature. The bypass connection with a self-bleeding dosing head is 6x4 mm.
Technical data
21
