ProMinent CONCEPTplus CNPb - Material specifications; Electrical specifications

Material Specifications
Material type Dosing head Suction/pressure
connector
Seals Valve balls
PPT Polypropylene Polypropylene PTFE Ceramic
PPE Polypropylene Polypropylene EPDM Ceramic
PPB Polypropylene Polypropylene FPM-B Ceramic
NPT Clear acrylic PVC PTFE Ceramic
NPE Clear acrylic PVC EPDM Ceramic
NPB Clear acrylic PVC FPM-B Ceramic
PVT PVDF PVDF PTFE Ceramic
Diaphragm: with a PTFE coating
Housing: PPE, fibreglass-reinforced
Electrical data
CNPb 100 ... 230 VAC ± 10%, 50 Hz/60 Hz
Specification 180 strokes/min 240 strokes/min
Nominal power 11.1 ... 10.5 W 14.3 ... 13.4 W
Current I eff 0.4 ... 0.2 A 0.46 ... 0.22 A
Peak current 1.5 A 1.5 A
Fuse* 1.6 AT 1.6 AT
* Fuses must have VDE, UL and CSA certification!
Technical data
