Technical data for the inputs (contact input, level input)
Data Value Unit
Voltage with open contacts 5 ± 0.5 VDC
Input resistance 12 ± 0.5 ㏀
Short circuit current 0.5 ± 0.05 mA
Maximum level for "0" signal 1.0 V
Maximum level for "1" signal 3.5 V
Minimum closing time of contact input 20 ms
Reaction time of level input 2 s
Temperatures
CAUTION!
The 240 stroke version may fail
The 240 stroke version can overheat at ambient temperatures higher than 35 ℃.
– Only use the 240 stroke version at ambient temperatures of less than 35 ℃.
Data Value Unit
Storage and transport temperature -10 ... +50 °C
Ambient temperature during operation -10 ... +45 °C
Maximum permissible medium temperature
Dosing head material Long term
at max. back pressure
For max. 15 min
at max. 2 bar
PPE / PPB / PPT 50 °C 100 °C
NPE / NPB 45 °C 45 °C
NPT 45 °C 60 °C
PVT 60 °C 120 °C
Technical data
23
