Component designation & scope of delivery
SCOPE OF DELIVERY
NO. DESIGNATION QUANTITY FIGURE
1
Frame set
1x frame
1x self-locking screw
for saddle attachment M8x35
1x washer M8
1x nut M8
1
2
Fork set
1x fork
2x bearing bushings
1
3
Handlebar set
1x handlebars
1x impact protection
2x grip
1
4
Wheel set
1x wheel 12"
2x drop out protection
2x cap nut M9
2
5 Saddle including mounted seat post 1
6
Cover for screw connection
handlebars/saddle
2
7
Screw set for handlebar attachment
1x clamp
1x self-locking screw M8x35
1x washer M8
1x nut M8
1
8 Decal set 1 not pictured
9 Multifunctional tool 1
10 Operating instructions 1
