Proscend 6200 SERIES - 2.3 WAN and LAN Connectivity

5
 Management
 Web and Telnet management via LAN ports
 CLI via serial console port
 Support SSH (RFC4250/4251/4252/4253/4254/4255/4256)
 SNMP v1/v2c/v3 (RFC 1157/1901//1905)
 MIB II (RFC 1213/1493)
 Syslog with Remote Logging support
 Firmware Upgrade via TFTP
 Configuration Data Import/Export
 Multiple Levels of Administration Privilege
 Support TR-069 WAN management protocol
 Physical / Electrical
 Dimensions: 18.7 x 3.3 x 14.5cm (WxHxD)
 Power: 100~240VAC (via power adapter)
 Power Consumption: 9 watts Max
 Temperature: 0~45ºC
 Humidity: 0%~95%RH (non-condensing)
Model Number list:
Model Number
Specification
6200-2W 6200-4W 6200-8W 6200-2W/U 6200-4W/U 6200-8W/U
Maximum DSL wires 2-wires 4 -wires 8-wires 2-wires 4 -wires 8-wires
Maximum data rate 5.696 Mbps
11.392
Mbps
22.784 Mbps 5.696 Mbps 11.392 Mbps
22.784
Mbps
USB port
USB port for 3.5G Dongle Modem with
Internet access backup
