Configuration as a Modbus Slave MVI56-MCM ♦ ControlLogix Platform
Modbus Communication Module
ProSoft Technology, Inc. Page 59 of 159
July 24, 2008
With the above configuration, this would be the addressing for the module.
Module Address Modbus Address Tag Address
100 47001 MCM.DATA.WriteData[100]
102 47002 MCM.DATA.WriteData[102]
104 47003 MCM.DATA.WriteData[104]
110 47006 MCM.DATA.WriteData[110]
120 47011 MCM.DATA.WriteData[120]
200 47051 MCM.DATA.WriteData[200]
300 47101 MCM.DATA.WriteData[300]
500 47201 MCM.DATA.WriteData[500]
