N93-586-84 Issue 04 AB Page 19 of 32 © Protec Fire Detection plc 2015
Access Level 4 (3500 cover removed, tool required)
• Configuration of global fire relay contact state (normally closed or normally open)
• Configuration of global fault relay contact state (normally closed or normally open)
• Configuration of alarm output activation type
• Global configuration of End of Line type (capacitive or resistive)
Configuration of panel at access level 4 is carried out using the locations of 4 links, accessible with the panel
door removed, shown in figure 6.0. (see appendix 2)
Figure 6.0 – Panel Configuration Links
Jumper Feature ON OFF
1 Configure Aux Fault Relay Contacts Normally Closed Normally Open
2 Configure Aux Fire Relay Contacts Normally Closed Normally Open
3
Configure Sounder Activation Global Sounder 1 = Call Point
Sounder 2 = Detector
4 Configure Zone EOL Capacitive Resistive
1
2
3
4
