6.9 Setting Zones into Test Mode
The 3500 permits zones to be programmed into walk test mode.
Activations from zones in walk test mode activate the alarm outputs for 10 seconds, after which the 3500
automatically resets. Activations from a zone not in test mode will operate as normal.
Activations from zones programmed as walk test DO NOT operate the global fire contacts.
Sequence Effect
Enter the access level 3 code 'Access Level' indicator flashes
Press button '2' to enter the walk test
menu
‘Test’ indicator flashes
Zone 1 indicator flashes
Any current walk test zones illuminate steady
Press buttons '2' or '3' to cycle round
zones
Cycles through zones to be programmed into walk test.
Selected zone flashes relevant indicator. Choices are:
Individual zones -> all zones
Press button '1' to enable walk test
mode
Relevant indicator changes to steady
Press button '4' to disable walk test
mode
Relevant indicator turns off
Press 'Enter' button to save and exit Saves current settings into memory and exits the menu
6.10 Delaying the Alarm Output Activation
An output delay may be programmed if required. In this mode a delay is introduced from detection of a zone
activation to activating the alarm outputs. The delay DOES NOT apply to the global fire contacts which will
operate immediately.
Sequence Effect
Enter the access level 3 code 'Access Level' indicator flashes
Press button '3' to enter the delays
menu
'Outputs Delayed' indicator illuminates
Zone 1 indicator flashes to show Alarm output 1 is selected
Any currently delayed alarms illuminate steady
Press button '2' or '3' to cycle round
the alarm outputs to be delayed
Cycles through delay choices. Selected alarm flashes the
relevant zone indicator. Choices are:
Individual alarms -> all alarms
Press button '1' to increment delay
time in minutes
Repeated presses of this button increase the delay
between 1 and 10 minutes. The delay is indicated by the
number of flashes shown on the 'Outputs Delayed' indicator
(5 flashes = 5 minutes, for example)
Press button '4' to disable delays Disables the delay on the selected alarm outputs
Press 'Enter' button to save and exit Saves current settings into memory and exits the menu
