N93-571-87 Issue 5 NH Page 16 of 34 © Protec Fire Detection plc 2019
13.3 The Fire Alarm Display
The 6100 enters the alarm state if one or more loop devices have triggered ( this may be because an
automatic detector has sensed a fire, or a Manual Call Point has been operated ).
The 6100 will activate its alarms as dictated by the system programming when commissioned.
The General Fire indicator will illuminate and ( if the alarm is in zones 1 to 16 ) the multifunction zone indicator
will flash red.
The LCD shows the fire display ( overriding any normal or fault displays ) as shown in Figure 13.2.
The display follows the format of displaying the first zone into fire on line 1, Latest zone into fire on line 2 and
the total number of zones in fire on line 3.
Figure 13.2 – 6100 Alarm Condition Display
The authorised user may press the
¿
key at this screen to retrieve more detailed information about any current
fires. The display will show details of the first device to generate an alarm , pressing the ▲ or ▼ keys will
rotate the displayed information showing the zone text for the device, the address text for the device then the
time and date at which the device generated the alarm.
Pressing the ◄ or ► keys scrolls through any further devices in fire.
The screen automatically returns to the standard 6100 fire display if no buttons are pressed for 30 seconds.
Figure 13.3 – Example of display showing information for the first device that generated an alarm
First fire zone 1
Latest fire zone 32
Fire in 32 zones
Enter for more info
Fire 1 of 3
Address 2 optical
zone 1
Dd / mm / yy HH:MM:ss
