N93-571-87 Issue 5 NH Page 18 of 34 © Protec Fire Detection plc 2019
14.3 Viewing Faults and Disablements
The VIEW FAULTS and the VIEW DISABLEMENTS menus allow the user to view any faults or disablements
currently on the 6100. Both these menus have the same basic format.
1. Enter the user code supplied with the system and press the
¿
key to access the menu system.
2. Using the ◄ and ► keys navigate to the VIEW FAULTS or VIEW DISABLEMENTS menu as required,
and press the
¿
key.
3. The first event is displayed, ( illustrated in figure 14.1 / 14.3 ) If there are no current events the 6100
will show the screen illustrated in figure 14.2 / 14.4, and an error tone will be issued.
4. Use the ◄ and ► keys to navigate to the previous or next event.
5. Use the ▲ and ▼ keys to toggle between the time of the event, the location text or the zone text.
Please note that depending on the event type some of the display options will not be available.
6. Press the
¿
key to exit the menu and return to the main menu.
Figure 14.1 View faults display, initial screen
Figure 14.2 No Faults to View Display
Figure 14.3 View Disablements Display
Figure 14.4 No Disablements Display Screen
View faults
No events to view
View disablements
No events to view
Dis 1 of 6
Zone disablement
Zone 3
Dd / mm / yy HH:MM:ss
fault 1 of 6
zone fault
zone 1
Dd / mm / yy HH:MM:ss
te
