N93-571-87 Issue 5 NH Page 23 of 34 © Protec Fire Detection plc 2019
14.12 Viewing the General Event Log
The VIEW GENERAL EVENT LOG menu allows the user to view any historic non-fire events.
1. Enter the user code supplied with the system and press the
¿
key to access the menus.
2. Using the ◄ and ► keys navigate to the VIEW GENERAL EVENT LOG menu and press the
¿
key.
3. The latest event is displayed first, as shown in figure 14.13 If there are no events in the log the 6100
will show the screen illustrated in figure 14.14, and issue an error tone.
4. Use the ◄ and ► keys to view the previous or next event.
5. Press the
¿
key to exit this menu and return to the main menu.
Figure 14.13 Illustration of View General Event Log display
Figure 14.14 No General Events display
14.13 Exiting the Menus
The EXIT MENU operation allows the user to exit from the menu and save any changes that may have been
made.
1. Using the ◄ and ► keys navigate to the EXIT MENU menu and press the
¿
key.
2. If no changes have been made the 6100 will return to the system status display. If changes have been
made then the save changes screen ( Figure 14.15 ) will be displayed. Using the ▲ and ▼keys select
whether to save changes.
3. Press the
¿
key to accept and return to the status display screen.
Figure 14.15 Save Changes display
Event 001
Device fault
DD / MM / YY HH:MM:SS
address 001
View general events
No events to view
