Getting Started
The mapping of the outputs is as follows:
The Protectowire Company, Inc.
FIBERSYSTEM 8000 - Linear Heat
Series
23
Pin assignment connector box 1
Output 1 - Error
Pin 1, 16
Output 2
Pin 2, 17
Output 3
Pin 3, 18
Output 4
Pin 4, 19
Output 5
Pin 5, 20
Pin assignment connector box 1
Output 6
Pin 6, 21
Output 7
Pin 7, 22
Output 8
Pin 8, 23
Output 9
Pin 9, 24
Output 10
Pin 10, 25
Output 11
Pin 11, 26
Output 12
Pin 12, 27
Output 13
Pin 13, 28
Output 14
Pin 14, 29
Output 15
Pin 15, 30
Output 16
Pin 31, 32
Output 17
Pin 33, 34
Output 18
Pin 35, 36
Output 19
Pin 37, 38
Output 20
Pin 39, 40
Output 21
Pin 41, 42
Output 22
Pin 43, 44
Pin assignment connector box2
Output 23
Pin 1, 16
Output 24
Pin 2, 17
Output 25
Pin 3, 18
Output 26
Pin 4, 19
Output 27
Pin 5, 20
Output 28
Pin 6, 21
Output 29
Pin 7, 22
Output 30
Pin 8, 23
Output 31
Pin 9, 24
Output 32
Pin 10, 25
Output 33
Pin 11, 26
