displays the next group of modulations as shown in Fig 9
Fig 9
Figure 9 shows the menu for selecting Phase shift key (psk),
Amplitude shift key (ask) and Burst modulations and their
corresponding soft button. Pressing the soft button that
corresponds to the < symbol returns the display to the previous
menu. Pressing the soft button corresponding to the > symbol
displays the next group of modulations and is shown in figure 10
Fig 10
Fig 10 shows the menu for selecting frequency modulation
(fm), Phase modulation (pm) and the amplitude modulation (am)
and their corresponding Soft buttons.
Pressing the soft button corresponding to the > symbol
displays the EXT amplitude selection menu and a waveform
Mode: Continuous
< psk ask burst >
Mode: Continuous
< fm pm am >
14
