Tw: the 0 phase shifted signal working time
Ts: the phase shifted signal working time
OK: Confirms the settings and starts the waveform
4.5 Amplitude shifting keying
Fig 17
Fo: Carrier frequency
Ph: Carrier phase shift
Tw: Carrier frequency duration
Ts: the time the next waveform starts
OK: Confirms the settings and starts the waveform
4.6 Burst (Pulse waveform)
Fig 18
Fo: Burst waveform frequency
Ph: the burst starting phase
Co: Number of cycles in the burst
Ts: the time the next burst starts
OK: Confirms the settings and starts the burst
4.7 FM
Fig 19
MODE: ASK
fo ph tw ts OK
MODE: BURST
fo ph co ts OK
MODE: internal FM
fo fm fd wa OK
