F1: Start frequency
F2: Stop frequency
Tw: Sweep time
Ts: the time when the next sweep starts
OK: Confirms the settings and starts the sweep
4.3 Frequency shift keying:
Pressing the soft button corresponding to FSK displays the
menu as shown in figure 15
Fig 15
F1: frequency 1
F2: frequency 2
Tw: the working time of frequency 1
Ts: the working time of frequency 2
OK: Confirms the settings and starts the waveform
4.4 Phase shift keying
Fig 16
Fo: Carrier frequency
Ph: phase difference
MODE: FSK
f1 f2 tw ts OK
MODE: PSK
fo ph tw ts OK
