Protek B8000FD Series User Manual

FIDE aK
(d)
(6)
4) Do not apply voltage to the output connector.
5) Do not apply voltage over 10V
P-P
to the input connector.
6)
. Do not use or store this instrument in a location near heat
source or in a place subject to high humidity.
7)
This instrument should only be serviced by a competent
electronics technician
2 Unit Description
10
4
5
8
9
6
3
2
3
Fig 1
1
7
2.0 Panel description
2.1 Front Panel outputs:
There are 3 BNC signal outputs on the front panel.
z Main OUTPUT:c Main output with an impedance of 50 Ω
z SYN:d This output is a TTL level signal which is active for
all waveforms except Sine and square waves. It is the
