---------) C._ ) C
) C
---
)
C----->
example, continuous (CW) which is displayed adjacent to
mode is the currently selected item. Pressing the soft
button corresponding to > displays the next group of
modulations.
6
Fig 2:
4) The front panel keysi are of 3 types. The first is the single
function buttons that displays waveform, frequency,
amplitude. DC offset and duty ratio values when pressed.
The Soft buttons are not used within these buttons.
5) The second type are the keys that display more than one
menu item on the LCD when pressed. The Mode and
Config keys are examples. These Soft buttons are used to
select items when multiple menu items are displayed.
6) The third type are execution buttons. The Enter key enters
waveform parameter values, the Esc key cancels an input
value after entering it from the key board. The direction key
(◄" & "►)j navigates through the displayed numerical
value on the LCD and the Trig key for performing single
cycle and external trigger waveform operations.
Mode: Continuous
CW Lin Log fsk >
To Next Page
