INSTALATION
Mounting the boiler 5.4
When mounting the boiler on the wall, proceed in accordance
with the installation design conditions (e.g. wall load bearing
properties, chimney inlet, pipe inlet and outlet connections).
The mounting procedure:
Take the paper template and attach it (for instance by -
adhesive tape) to the place of installation. When positioning
the template, user a plumb line or a spirit level.
Using the marked points on the template, drill all necessary -
holes (mounting bar, connecting ramp).
If combustion gas discharge is to be directly via the building’s -
façade, project and mark a point for a pass of the concentric
ducting.
Remove paper template. -
Drill the required holes, respecting the diameters shown in -
the template.
Insert wall plugs into the holes for the mounting bar and then -
fasten the bar properly with the screws provided.
Hang the boiler on the mounting bar. -
Install the combustion gases removal ducting onto the boiler. -
Fill-in the gaps between the ducting and the wall opening
with a non-fl ammable material.
Remove the plastic plugs from the boiler outlets. -
Install the protective fi lter to the heating water inlet (not part -
of delivery).
Mount isolation valves on all outlets from the boiler (not part -
of delivery).
Connect heating water, hot water and gas distribution pipes -
to the isolation valves.
Install lever for topping up water into the heating system. -
Fill boiler with water. -
Perform check of tightness of all connections. -
