INSTALATION
Air and exhaust lines7
1
3
4
2
5
6
Legend
1 chimney - 110 mm pre 12 kW, 125 mm pre 25 kW
2 over-fl ow safety device
3 draught diverter
4 heat exchanger
5 combustion chamber
6 burner - 13 blades
