- 22 -
INSTALATION
Code Description Manufacturing
setting
Minimum
value
Maximum
value
00 Heating part load, adjustable values in kW following power range
01 Central Heating Pump Overrun (min) 5 2 60
02 Maximum off period after central heating operation (min) 20 2 60
03 Domestic hot water fl ow temperature (°C)
04 Tank or micro-accumulation temperature (°C)
Only displayed when tank NTC connected
09 Nominal fl ow temperature from external eBus control (°C)
Only displayed if an eBus control is connected
10 Internal pump:
1 = on
0 = off
11 External pump:
1 = on
0 = off
12 Cylinder storage pump:
1 = on
0 = off
13 Circulation pump:
1…100 = on
0 = off
16 24V room thermostat
0 = open (no heating),
1 = closed (heating mode)
17 Type of temperature regulation: fl ow / return 0 0 1
18 Pump mode (post-run)
0= with burner
1= with RT
2= winter mode
102
19 Function mode of 2 speed pump mode setting:
0: burner mode = stage 2,
pre/post-run = stage 1;
1: CH + post-run = stage 1, DHW = stage 2,
2: automatic in CH, pre/post-run = stage 1,
DHW : stage 2
3: always stage 2
details see functional description
203
20 Maximum set value of the DHW setpoint (°C) 60 50 60
21 Warmstart function enabled and allowed
1 warmstart function enabled and allowed
0 warmstart function disabled or not allowed
01
22 DHW demand active (tank or tapping) :
1=on
0=off
23 Release of central heating
1 = CH release
0 = CH not released
24 air pressure switch
1: closed
0: open
25 Tank heating state
1=tank heating enable
0=tank heating disabled
27 Switching option relay 1 1 1 10
28 Switching option relay 2 2 1 10
31 Filling loop mode
0. manual
1. Semi-automatic
2. Full automatic
002
35 Position setpoint of the TWV
100 = DHW
0 = heating
40 = middle position
