INSTALATION
Code Description Manufacturing
setting
Minimum
value
Maximum
value
36 DHW waterfl ow sensor (l/min)
40 Flow temperature (°C)
41 Return temperature (°C)
43 Heating curve
Displayed only when outdoor T° sensor connected and no ebus control (sending a valid
CH setpoint) connected
1,2 0,2 4
44 Digitalized ionisation voltage (V)
45 Heating curve - base point adjustment
Displayed only when outdoor T° sensor connected and no ebus control (sending a valid
CH setpoint) connected
20 15 25
47 Outside temperature (°C)
Displayed only when outdoor T° sensor connected to the BMU
52 Offset for minimum steppermotor position (1 means 2 steps for motor with 480 steps) 45 0 99
53 Offset for maximum steppermotor position (1 means 2 steps for motor with 480 steps) -25 -99 0
62 Night/Day offset 0030
64 Average ignition time (s)
65 Maximum ignition time (s)
66 Disable warmstart function
0 : Warmstart disabled
1 : Warmstart enabled
101
67 Remaining burner blocking time (min)
68 Number of unsuccessfull ignitions at fi rst attempt
69 Number of unsuccessfull ignitions at second attempt
70 Three way valve working mode
0 : TWV in normal mode (heating position for heating and DHW position for DHW)
1 : TWV in permanent middle position
2 : TWV in permanent heating position
Only displayed and adjustable on system boilers
002
71 Maximum nominal value of fl ow temperature (°C) 75 45 80
77 Part load hot water in (kW)
Only displayed and adjustable on system boilers
závisí od výkonového rozsahu kotla
80 Operating hours in heating mode (h)
81 Operating hours in domestic hot water mode (h)
82 Number of burner starts in heating mode
83 Number of burner starts in DHW mode
85 Minimum power of the appliance (kW) závisí od výkonového rozsahu kotla
90 Digital control recognized:
1 = yes
0 = no
93 Adjustment of Device Specifi c Number
G20
0: 12 KOO
1: 12 KTO
2: 25 KOO
3: 25 KOV
4: 25 KTO
5: 25 KTV
6: 30 KTV
G31
1: 12 KTO
4: 25 KTO
5: 25 KTV
6: 30 KTV
7: 12 KOO
8: 25 KOO
9: 25 KOV
09
94 Reset fault codes list 0 0 1
95 Software Version of PeBus participiants
1. BMU
2. AI
