Protherm PTCP - Wiring and Connection

INSSTCP0408
placeoranyotherheatsource;
• closeorinfrontofanairoutlet;
•closetoconcealedductsorachimney;and
•in a location with poor air ow (e.g. behind adoor), or with
frequent air drafts (e.g. head of stairs).
To install the sensor, refer to the installation guide of your heat-
ing floor.
Thermostat Mounting and Connection
1. Cut off power supply on lead wires at the electrical
panel in order to avoid any risk of electric shock.
2. Ensure that the air vents of the thermostat are clean and clear
of any obstruction.
3.Usingascrewdriver,loosenthescrewretainingthemounting
base and front part of the thermostat. Remove the front part of
the thermostat from the mounting base by tilting it upward.
