Protimeter MMS2 - Surface Temperature IR (Non-Contact)

14 INS8800 Rev. D
Protimeter MMS2 Instruction Manual
4.5b Surface Temperature IR (Non-Contact Based) - Selection
and Use (cont.)
Figure 5: LASER Pointer
Table 3: TDIFF Readings
T. DIFF (DEGC) Condensation Status Progress Bar
<0 Condensation
Red
>0 but <3 Risk of Condensation
Yellow
>3 No Condensation
Green
