Protimeter MMS2 User Manual

INS8800 Rev. D 15
Protimeter MMS2 Instruction Manual
4.6 Logging - Selection and Use
The MMS2 supports both continuous and manual logging.
4.6a Manual Logging
If is pressed at any of the measurement screens, the data and Timestamp at
that instant will be logged and a
RECORD SAVED message will be displayed on
the bottom bar.
4.6b Continuous Logging
Continuous logging is used to sample and store data continuously. Continuous
logging is enabled either by setting logging parameters through the Keypad or
through a PC using MMS2 Logging Software. (see Section 4.7g, “Set Logging
Parameters (Optional PC Logging Software Required)”, on page 19.)
After the logging parameters are saved, logging starts after the START AFTER
minutes have elapsed. The logging icon is displayed on the top right
corner of the screen while logging is active.
When logging is in progress, an option to stop logging is provided under the
SETTINGS menu. Logging can be stopped either by selecting SELECT MODE ->
SETTINGS -> STOP LOGGING in the instrument, by clicking STOP LOGGING in
the MMS2 Logging Software or when the instrument is turned OFF.

Protimeter MMS2 Specifications

General

Measurement Modes	Pin, Non-Invasive, Humidity, Temperature
Depth of Measurement (Non-Invasive)	Up to 3/4 inch (19 mm)
Humidity Measurement Range	0% to 100% RH
Temperature Measurement Range	-4 to 140 °F (-20 to 60 °C)
Accuracy (Relative Humidity)	±2% RH
Accuracy (Temperature)	±0.5 °C
Display	LCD
