Protimeter MMS2 User Manual

INS8800 Rev. D 3
Protimeter MMS2 Instruction Manual
3. Product Components and Accessories (cont.)
D - This USB socket is for connection to a PC when using the optional MMS2
logging software.
Figure 1: Connections for Probes and Sensors
• The Hygrostick (POL4750), Quikstick (POL8750) and Short Quikstick
(POL8751) probes measure relative humidity (%RH) and ambient air
temperature in rooms or materials. They can be connected to the MMS2
instrument either directly or by means of the extension lead.
• The surface temperature sensor is used when investigating condensation
situations.
• The moisture probe is used to obtain percent moisture content values in
wood or wood moisture equivalent (WME) values in other non-
conductive materials.
• Multiple probe types are available, including hammer probes and deep
wall probes.
C
B
Search Mode Sensor
Non-contact Surface Temperature Sensor (IR)
Laser
D
A

Protimeter MMS2 Specifications

General

Measurement Modes	Pin, Non-Invasive, Humidity, Temperature
Depth of Measurement (Non-Invasive)	Up to 3/4 inch (19 mm)
Humidity Measurement Range	0% to 100% RH
Temperature Measurement Range	-4 to 140 °F (-20 to 60 °C)
Accuracy (Relative Humidity)	±2% RH
Accuracy (Temperature)	±0.5 °C
Display	LCD
