Proton Products InteliSENS DG2030 Diameter Gauge Instruction Manual (Issue 1a)
DW Bit Comments Unit Range/Remark Default value
3
limit;7=Under Average
Lower limit;8=Over X
Upper limit;9=Under X
Lower limit;10=Over Y
Upper limit;11=Under Y
Lower limit;12=Over Z
Upper limit;13=Under Z
Lower limit;14=Over
ovality Upper
limit;15=Under Ovality
Lower limit;,
4
Relay 2 function 1
5
6
7
8
Relay 3 function 2
9
10
11
12
Relay 4 function 3
13
14
15
DW51 Relay closure time 1=1ms 1~5000 100
DW52 Source of line speed
0=Preset;1=Pulse;2=An
alouge
0
DW53 Preset line speed 1=1m/min{1=ft/min} 0~65535 1000
DW54
Full scale/gain of line
speed
1=1m/min{1=1ft/min)
or
1=0.0001pulse/meter{
1=0.0001pulse/ft)
1000
DW55
DW56
0~
7
Control switch
0=HOLD;1=ON;2=RES
ET
0
8 Control output polarity 0=Normal;1=Reverse 0
DW57 PID Start Speed 1=1m/min{1=1ft/min} 50
DW58 PID output Range 1=1% 0~50% 50
DW59 Extruder response time 1=1s 0~999s 1
DW60
Distance from gauge head
to extruder
1=0.1m{1=0.1ft} 1~10000 10
DW61 I gain 1=1% 0~100 50
DW62 P gain 1=1% 0~100 50
DW63
Analogue O/P
0
Analogue O/P 1
0=Average ;1=X;2=Y;3
=Z;4=Ovality;5=Averag
e error;6=X error;7=Y
error;8=Z
error;9=Ovaity error;
0
1
2
3
4
Analogue O/P 2 1
5
6
7
8 Analogue O/P 3 2
