Proton InteliSENS DG2030 User Manual

Page 64 of 69
Proton Products InteliSENS DG2030 Diameter Gauge Instruction Manual (Issue 1a)
DW Bit Comments Unit Range/Remark Default value
DW89 Modbus ID 1=1 0~255 1
DW90 ETH DHCP 0=Disable;1=Enable 0
DW91 iBus DHCP 0=Disabled;1=Enabled 0
DW92
ETH IP address xx.xx.xx.xx
C0A80164
(192.168.1.17
0)
DW93
DW94
Rev
DW95
DW96
Subnet mask xx.xx.xx.xx 255.255.255.0
DW97
DW98
Gateway xx.xx.xx.xx
C0A80101(19
2.168.1.1)
DW99
DW100
iBus IP Address
C0A80165
(192.168.1.17
1)
DW101
DW102
iBus Subnet Mask
FFFFFF00(25
5.255.255.0)
DW103
DW104
iBus Gateway
C0A80101(19
2.168.1.1)
DW105
DW106
Destination IP address for
UDP (last section only)
Port number fixed to
1111
2
DW107
Interval time of UDP data
output
1=1ms
0~5000(0=disable UDP
output)
0
DW108 Little Endian/Big Endian
1=Little Endian;0=Big
Endian
1
DW109 CAN terminator 1=1 0=OFF;1=ON 1
DW110
DW111
DW112
DW113
DW114
DW115
DW116
Diameter compensation
coefficient
1=0.0001 10000
DW117 WIFI switch
DW118 Gain of analogue O/P1 1=1 10000
DW119 Zero of analogue O/P1 1=1 0
DW120 Gain of analogue O/P2 1=1 10000
DW121 Zero of analogue O/P2 1=1 0
DW122 Gain of analogue O/P3 1=1 10000
DW123 Zero of analogue O/P3 1=1 0
DW124
