Proton Products InteliSENS DG2030 Diameter Gauge Instruction Manual (Issue 1a)
OUTPUT PARAMETERS
DW Bit Comments Units Range/Remark
DW0
0
Measurement Mode 0=Solid;1=Glass;2=Helix 1
2
3 Unit 0=Metric;1=Imperial
4 Shrinkage mode 0=Percentage;1=ABS
5 High Resoulation for Diameter 0=OFF;1=ON
6 Over average upper limit 0=OK;1=Over limit
7 Under average lower limit 0=OK;1=Over limit
8 Over X upper limit 0=OK;1=Over limit
9 Under X lower limit 0=OK;1=Over limit
10 Over Y upper limit 0=OK;1=Over limit
11 Under Y lower limit 0=OK;1=Over limit
12 Over Z upper limit 0=OK;1=Over limit
13 Under Z lower limit 0=OK;1=Over limit
14 Over ovality upper limit 0=OK;1=Over limit
15 Under ovality lower limit 0=OK;1=Over limit
DW1
0 Res
1 No reading 0=OK;1=No Reading
2 No object 0=OK;1=No Object
3 Lens dirty 0=OK;1=Lens Dirty
4 Line speed too low in helix mode 0=OK,1=too low
5 Line speed too high in helix mode 0=OK,1=too high
6 Gauge too hot 0=OK;1=Gauge Hot
7
8 External Alarm 1 0=OK,1=Alarm
9 External Alarm 2 0=OK,1=Alarm
DW2
Average diameter/Envelop 1=0.01um{mil} 0~20000000
DW3
DW4
X diameter 1=0.01um{mil} 0~20000000
DW5
DW6
Y diameter 1=0.01um{mil} 0~20000000
DW7
DW8
Z diameter 1=0.01um{mil} 0~20000000
DW9
DW10 Ovality 1=0.01um{mil} 0~20000000
