Proton InteliSENS DG2030 User Manual

Page 67 of 69
Proton Products InteliSENS DG2030 Diameter Gauge Instruction Manual (Issue 1a)
DW Bit Comments Units Range/Remark
DW11
DW12
Average error/Envelop Error 1=0.01um{mil} -20000000~20000000
DW13
DW14
X error 1=0.01um{mil} -20000000~20000000
DW15
DW16
Y error 1=0.01um{mil} -20000000~20000000
DW17
DW18
Z error 1=0.01um{mil} -20000000~20000000
DW19
DW20
Ovality error 1=0.01um{mil} -20000000~20000000
DW21
DW22
Latest lump value 1=0.01um{mil} -20000000~20000000
DW23
DW24
Latest lump positon 1=0.001m{1=0.001ft} 0~100000000
DW25
DW26
Latest neck value 1=0.01um{mil} -20000000~20000000
DW27
DW28
Latest neck position 1=0.001m{1=0.001ft} 0~100000000
DW29
DW30 Lump count 1=1 0~65535
DW31 Neck count 1=1 0~65535
DW32
Running maximum diameter 1=0.01um{mil} 0~20000000
DW33
DW34
Running minimum diameter 1=0.01um{mil} 0~20000000
DW35
DW36
Running average diameter 1=0.01um{mil} 0~20000000
DW37
DW38 Cable position on X axis 1=1% 0~±100
DW39 Cable position on Y axis 1=1% 0~±100
DW40 Cable position on Z axis 1=1% 0~±100
DW41 Line speed 1=0.1m/min{1=1ft/min} -32768~32767
DW42
Length 1=0.001m{1=0.001ft}
DW43
DW44
Statistics
0 Normal distribution 0=No;1=Yes
1 Not used
2 SPC is available 0=No;1=Yes
DW45 Statistics remain time 1=1s{1=1m{ft}} 0~65535
DW46
Standard deviation 1=0.01um{mil} 0~20000000
DW47
