DW Bit Comments Units Range/Remark
DW48
Maximum diameter 1=0.01um{mil} 0~20000000
DW49
DW50
Minimum diameter 1=0.01um{mil} 0~20000000
DW51
DW52
Mean diameter 1=0.01um{mil} 0~20000000
DW53
DW54 Chi of normal distribution 1=1% Not used
DW55 Cp 1=1%
DW56 Cpk 1=1%
DW57 FFT remain time 1=1s
DW58 Control status 0=OFF;1=ON;2=Reset;3=Ready
DW59 Control output 1=0.01% 0~±10000
DW60
DW61
DW62 Communication Bus Type
0=NONE;1=PROFIBUS;2=Ethernet
/IP;3=PROFINET
DW63 Res
DW64
IP address for ETH xx.xx.xx.xx
DW65
DW66
IP address for iBUS xx.xx.xx.xx
DW67
DW68
Sub net Mask xx.xx.xx.xx
DW69
DW70
Gateway xx.xx.xx.xx
DW71
DW72 Gauge temperature 1=0.1℃
