5.3.6 Snap
In this interface, user can set up resolution, quality, snap interval, snap number.
5.4 Schedule Configuration
Schedule configuration includes three sub menus: schedule, motion and sensor.
5.4.1 Schedule
This tab allows defining schedule for normal recording for seven days of a week, 24 hours of a day. Every
row denotes an hourly timeline for a day. Click the grid to do relevant setup. A highlighted area denotes
selected timeline. Operate the following steps to set schedule:
Step 1: Enter into MenuSetupSchedule interface. Refer to Fig 5-14:
Fig 5-14 Schedule Configuration-Schedule
Step 2: Select channel and click “ ” button to add a certain day schedule. Click “ ” button to delete
the selected schedule.
If you want to apply the schedule setting of a certain channel to other or all channels, you need to select
channel and click “Copy” button.
You can also set week schedule by double-clicking in the grinding area. This will take you to see a dialog
box as Fig 5-15.
Step 1: Select a day and click “Add” button to schedule start time and end time. Then click to save.
Step 2: Select other days and add schedule or copy settings from one schedule to the others under the
Apply Settings To item.
Fig 5-15 Schedule-Week Schedule
