Prowinch PWA - Motor and Body Assembly Parts List

Version 1.0
Parts
28
28
1.2 Motor and body assembly parts list
No. Part Name No. Part Name
1 Tracon Wheels 30 Terminal
2 Hexagon bolt 31 Cover
3 Flat washer 32 Holding xture
4 Spring washer 33 Holding xture
5 Support Structure 34 Safety switch
6 Rope roll shi 35 Breaker contactor
7 Flat key 36 Locang pin
8 Flat key 37 Spring tab
9 Elasc collar 38 Locknut
10 Bearing 39 Hook washer
11 Hexagon llister head screw 40 Hook
12 Gear case 41 Hexagon Bolt
13 Gear 42 Hexagon Bolt
14 Flat washer 43 Wheel axle
15 Gear wheel 44 Splint
16 Cushion board 45 Pulley
17 Front cover 46 Hook xed nut
18 Bearing 47 Gear Sha
19 Stator 48 Bearing
20 Stator cover 49 Hexagon bolt
21 Rotor 50 Limiter
22 Tripping spring 51 Hook
23 Brake Component 52 Rope thimble
24 Bearing 53 Aluminum pipe
25 A closure 54 Block
26 Fan 55 Wire rope
27 Fan cover 56 Rope roll
28 Hexagon bolt 57 Wedge
29 Juncon box 58 Bushing
