Tsunami
®
800 & 8000 Series - Software Management Guide 127
After configuring the required parameters, click OK and then COMMIT.
Listed below are the points to be noted before configuring the Radius Server Profile,
1. Message Response Time should always be less than WORP Registration Timeout.
2. If Max Retransmissions is configured as Zero, then retransmissions do not occur.
3. The value of Max Retransmissions multiplied by Message Response Time should be less than WORP
Registration Timeout value.
5.5.3 MAC ACL
:Applicable only to a BSU and End Point A device.
The MAC ACL feature allows only the authenticated SUs/End Point Bs to access the wireless network. Please note that MAC
Authentication is supported only on the wireless interface. The MAC ACL feature is applicable only when it is enabled in the
WORP Configuration page (See
{ B D
B E
).
To configure the MAC Access Control List, navigate to ADVANCED CONFIGURATION > Security > MAC ACL. The MAC
Access Control screen appears:
Figure 5-55 MAC Access Control Configuration
IP Address Represents the IPv4 / IPv6 address of the primary and secondary RADIUS servers.
: IPv6 address should be the global IP address and not the link local IP address.
Server Port Specifies the port number that is used by the BSU/End Point A and the RADIUS server to
communicate. By default, RADIUS Authentication Server communicates on port 1812.
Shared Secret Specifies the password shared by the BSU/End Point A and the RADIUS server to
communicate. The default password is public.
Care should be taken to configure same Shared Secret on both BSU/End Point A and
RADIUS Server, otherwise no communication is possible between BSU/End Point A and
RADIUS server.
Entry Status You can either enable or disable the configured RADIUS servers. By default, the Primary
RADIUS server is enabled and the secondary RADIUS server is disabled.
Parameter Description
