Mounting positions
Outdoor usage:
When using actuators in environments with high
temperature fluctuations or high humidity, we suggest a
heating resistor to be fitted to prevent the build-up of
condensation within the enclosure.
Figure 2: Mounting positions
3. Manual operation
Figure 3: Manual operation
For commissioning the actuator
during adjustment work (valve
mounting and end position
adjustment), an electrical manual
override by means of a push-button
is available (see 10.).
