PS Automation PSF-Q Short Operating Instructions

9
7.4 Status display
Green LED
Red LED
Actuator not commissioned
Off
Is flashing quickly
Normal operation / Actuator running
On
Off
Normal operation / Actuator stationary
Off
On
Manual mode active
Is flashing alternately
Is flashing alternately
Manual mode: output valve shaft
counterclockwise (CCW)
Off
Is flashing
Manual mode: output valve shaft
clockwise (CW)
Is flashing
Off
Automatic commissioning running
On
On
Automatic and manual commissioning
successful
Is flashing 7 x – 1.5 seconds off
On
Automatic commissioning failed
Is flashing quickly
On
Overvoltage
Is flashing 1 x – 1.5 seconds off
On
Undervoltage
Is flashing 2 x – 1.5 seconds off
On
Memory error
Is flashing 3 x – 1.5 seconds off
On
Set value error (< 1 V, < 2 mA)
Is flashing 4 x – 1.5 seconds off
On
Torque error
Is flashing 5 x – 1.5 seconds off
On
Under- / overtemperature
Is flashing 6 x – 1.5 seconds off
On
Blue LED: Ready for operation status, when supply voltage is applied. LED glowing makes reading the position of the
DIP switches easier.
8. Operation
All internal parameters, like required motor torque, actual position, functional status, etc., are being permanently
monitored during operation of the actuator PSF. This ensures that the actuator positions with optimum accuracy,
and closes the valve always tightly.
Cut-off in end positions
Depending on the selected switch position S2-3/4/9, it is determined how the actuator approaches an end position.
When selecting "closing/opening with torque", the end position retraction of 3% is active in both directions, in which
case switch S2-1 has no function. In the operating modes "opening with swing angle", the actuator remains in the
open position that was set during automatic or manual calibration. The end position to be reached by torque is
always approached with a retraction of 3%.
