PS Automation PSF-Q Short Operating Instructions

8
7.3 Operator push buttons
Function
Action
Push button B1
Push button B2
LED sequence
Manual
Operation
Activate
> Push 3 seconds
> Push 3 seconds
Both LEDs are flashing
alternately
output valve shaft
clockwise (CW)
Push
Green LED is flashing
output valve shaft
counterclockwise (CCW)
Push
Red LED is flashing
Stop
Both LEDs are flashing
alternately
Exit
> Push 3 seconds
> Push 3 seconds
Red or green LED is on
Automatic
commissioning
Start
> Push 7 seconds
Both LEDs are on
Commissioning finished
Green LED is flashing 7x
(if commissioning is
finished),
green LED is flashing
quickly
(if commissioning failed)
Exit
Push 1 x
Red or green LED is on
Manual
commissioning
Activate
> Push 7 seconds
Both LEDs are flashing
alternately
output valve shaft
clockwise (CW)
Push
Green LED is flashing
output valve shaft
counterclockwise (CCW)
Push
Red LED is flashing
Start
> Push 3 seconds
> Push 3 seconds
Both LEDs are on
Exit
Push 1 x
Red or green LED is on
