TO AI DEVICES
FROM POWER
SUPPLY AND
CONTROLLER
TO GATE OR
DOOR STRIKE
NOTE: IF 2 GATES:
ARM = RELAY 1
SLIDE = RELAY 2
RELAY 2 CAN BE TIMED.
CAMERA
P1
K1 K2
P4
RELAY 1 RELAY 2
NO1
C1
NC1
NO2
C2
NC2
4 651 2 3
Drawing 17: Gate operator wiring
