Door Strike
The door strike connection is similar to a gate operator connection,
except that the door strike requires power supplied by an external
power supply. The type of door strike determines the power
supply used.
Do NOT use the same power supply that provides power to
the APEX device.
Refer “Drawing 18: Door strike wiring” on page 22 to for details
of connecting the door strike
Inputs 1 and 2 cannot be used for any other function while
Extended Door Controls are enabled.
If extended door controls are used
Door strike must be connected to Relay 1
Door contact must be connected to Input 1
(if used) Request to exit device must be
connected to Input 2
APEX Access Device
21
rev. 7-2017 114A3863.E
