Pulsar FORWARD FN455 User Manual

ENGLISH
Specications
MODEL FORWARD FN 455
SKU# 78196
OPTICAL SPECIFICATIONS
Len focus, mm 50
Relative aperture (D/f) 1:1
Field of view (horizontal), ° 6.3
Field of view (horizontal), m @ 100m 11
Detection distance of an animal 1.7 m high, m 500
Minimum focusing distances, m 5
Recommended magnication of the daytime optical device, x 2-8
ELECTRONIC SPECIFICATIONS
Sensor type and resolution CMOS HD 1280X720
Display type and resolution AMOLED 1746x1000
Device sensitivity (wavelength 780nm, 25 pieces/mm resolution), mW 1.5 × 10
-
⁵
Device sensitivity (wavelength 915nm, 25 pieces/mm resolution), mW 5.5 × 10
-
⁵
DETACHABLE IR ILLUMINATOR
Type / wavelength, nm LED 940
OPERATING FEATURES
Power supply, V 3.0–4.2
Battery type / capacity / Output rated voltage
Li-Ion Battery Pack
IPS5 / 5000 mAh /
DC 3.7V
External power supply Micro USB type B (5V)
Battery life at temp. = 22 ° C (Wi-Fi off, IR off), hrs 9
IP code (IEC60529) degree of protection IPX7
Operating temperature, °C/°F -25 ÷ +50 / -13 ÷ +122
Dimensions, mm/inch
155х136х77 /
6.1х5.35х3.03
Dimensions when Pulsar monocular is used, mm/inch
264х136х77 /
10.39х5.35х3.03
Weight, kg/oz 1.03 / 35.27
VIDEO RECORDER
Video / photo format .mp4 / .jpg
Amount of built-in memory 16 GB

Frequency 2.4 GHz
Standard 802.11 b/g
Improvements may be made to the design and software of this product to
enhance its user features.
– The current version of the User’s Manual may be found on the website
www.pulsar-vision.com
Repair of the device is possible within 5 years.
8

Pulsar FORWARD FN455 Specifications

General

Sensor	CMOS
Magnification	1x
Objective Lens Diameter	50 mm
Dimensions	155x136x77 mm
Waterproof	IPX7
Resolution	1280x720
Detection Range	Up to 500 meters
IR Wavelength	940 nm
Battery Life	Up to 9 hours
Operating Temperature	-25 to +50 °C
Weight	830 g
Minimum Focusing Distance	5m
IR Illuminator	Yes
Battery Type	B-Pack (Li-ion)
