Pulsar FORWARD FN455 User Manual

ENGLISH
ENGLISH
Delivery package
• Digital module
• Pulsar 5x30 monocular
• Case
• IPS5 rechargeable battery
• Battery charger
• Mains charger
• MicroUSB cable
• Quick start guide
• Cloth for cleaning optics
• Warranty card
Electromagnetic compatibility.
This product complies with the requirements of European Standard EN 55032:2015, Class A.
Caution: Use of this product in a residential area may cause radio interference.
Units and controls
1. Lens cap
2. Eyepiece cover
3. Battery compartment cover
4. Battery installation lever
5. Rechargeable battery
6. RIGHT button
7. M (MENU) button
8. LEFT button
9. ON button
10. Lens focus ring
11. IR illuminator cover
12. IR illuminator connector cap
13. Connector for installing IR illuminator
14. MicroUSB port
15. Weaver bar
16. Adapter cover*
17. Optical device observation lens
18. Insert*
19. Adapter*
20. Tightening screw
21. Screw
22. Adapter arm
23. Attachment point
24. IR button
25. IR illuminator arm
*Items of Cover Ring Adapter FN (available separately)
1

Pulsar FORWARD FN455 Specifications

General

Sensor	CMOS
Magnification	1x
Objective Lens Diameter	50 mm
Dimensions	155x136x77 mm
Waterproof	IPX7
Resolution	1280x720
Detection Range	Up to 500 meters
IR Wavelength	940 nm
Battery Life	Up to 9 hours
Operating Temperature	-25 to +50 °C
Weight	830 g
Minimum Focusing Distance	5m
IR Illuminator	Yes
Battery Type	B-Pack (Li-ion)
