Adding /Check ing Engine Oil
Place generator on a level surface.
Remove screws and then remove the outer casing cover.
Remove the crankcase dipstick.
Insert a funnel into the crankcase dipstick hole and carefully add the specified amount of 4-Cycle engine oil (SAE 10W-
30) to empty reservoir until or oil reaches the outer edge of the oil fill hole (crankcase dipstick hole).
Be sure to replace dipstick and securely tighten before attempting to start the engine.
To check oil, set generator on a level surface, wipe dipstick clean, then reinsert dipstick without re-threading.
Recommended Oil: SAE 10W-30
Oil Capacity: 0.35L (11.8oz)
12
CAUTION!
generator. Always check oil level before each operation.
