5.2.20 Adjusting the centre point of gravity
Preparation
Switch off the wheelchair via the remote control.
Instructions
• Remove the leg rests.
• Loosen the 4 bolts.
• Move the whole chair unit to the correct position.
• Remount the 4 bolts.
• Replace the leg rests.
Notice
Changing the wheelchair’s centre of gravity may negatively
infl uence the wheelchair's driving characteristics and/or its
dynamic stability! Therefore it might be sensible to use the
RWD hole for a FWD and vice versa
Relevant article numbers
9002592 M8x12 CKS BZK PRECOTE 85
00000.2003 Locking ring, fl at M8
Tools used
Allen key, 6 mm
Icons
Parts need to be replaced. Dispose of waste parts
in accordance with local regulations.
Note! Be aware of the issue!
1
Note! Suitable work area required!
2
3
Note! Lift the chair in case the wheel chair has an electrical lift.
4
100 | Service instructions Puma 20/40/60100 | Service instructions
