Electric diagrams DX2 (1)
DX2 Drive & Lights
Cable lenghts are not drawn to scale
Lighting
6000038
6000039
6000038
6000039
DX2 2 Puma2040
9006312
(If there is a li ft, use: 9006313)
Lighting
PM
00355.0024 (2m)
JSM
Batteries
1x 100A
9006230
9006231
Motor Motor
DX2 Battery & Motor connections (Drive only)
00355.00 24 (2m)
Cable lenghts are not drawn to scale
DX2 1 Puma2040
PM
JSM
